Switch L2+ Grandstream GWN7801P
Giá bán: Liên hệ
Thông tin sản phẩm
Switch L2+ Grandstream GWN7801P
2 cổng SFP, 8 cổng gigabit,Công suất ra PoE 120W cho dòng GWN7801P, Hỗ trợ Vlan, IGMP, DHCP server., Quản lý Cloud, GWN manager, Https, CLI, TR069.,Sử dụng cho PC, Camera, Wifi, IP phone, Hàng thương hiệu Mỹ, chất lượng USA
Mô tả sản phẩm
Switch L2+ Grandstream GWN7801P
- 2 cổng sfp và 8 cổng mạng gigabit,
- PoE out max 120 wat, PoE mỗi port max 30 wat
- Hỗ trợ Vlan, IGMP, DHCP server..
- Quản lý Cloud, GWN manager, Https, CLI, TR069..
- Sử dụng cho PC, Camera, Wifi, IP phone.
Switch L2+ Grandstream GWN7801P
| Model | GWN7801P |
| Network Protocol | IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3af/at, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1d, IEEE 802.1s |
| Gigabit Ethernet Ports | 8 |
| Gigabit SFP Ports | 2 |
| Console | 1 |
| PoE Ports | 8 |
| Integrated Power Supply | 150W |
| Max Output Power per PoE Port | 30W |
| Max Total PoE Output Power | 120W |
| PoE Standards | IEEE 802.3af/at |
| Surge Protection | ± 6KV CM and DM for power ± 4KV CM and ±2KV DM for network ports |
| Auxiliary Ports | 1x Reset Pinhole |
| Forwarding Mode | Store-and-forward |
| Total non-blocking throughput | 10Gbps |
| Switching Capability | 20Gbps |
| Forwarding Rate | 14.88Mbps |
| Packet Buffer | 4.1MB |
| Switching | 8K static, dynamic and filtering MAC addresses 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN VLAN virtual interface GVRP 8 link aggregation groups Spanning tree, 64 instances for STP/RTSP/MSTP |
| Multicast | IGMP Snooping, MLD Snooping, MVR |
| QoS/ACL | • Auto detection and prioritization of voice/video/RTP/SIP/other latency-sensitive packets • Port priority • Priority mapping • Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ • Traffic shaping • Rate limit • 1.5K ACL for Ethernet, IPv4 and IPv6 |
| DHCP | DHCP server, DHCP relay, Option 82, 60,160 and 43 |
| Maintenance | CPU and memory monitoring, SNMP, RMON, LLDP&LLDP-MED, backup and restore, syslog, alert, diagnostics including Ping, Traceroute, port mirroring, UDLD(TBD) and copper test |
| Security | • User hierarchical management and password protection, HTTPS, SSH, Telnet • 802.1X authentication • AAA authentication including RADIUS, TACACS+ • Storm control • Port isolation, port security, sticky MAC • Filtering MAC address • IP source guard, DoS attack prevention, ARP inspection • DHCP Snooping • Loop protection including BPDU protection, root protection and loopback protection • Kensington Security Slot (Kensington Lock) support |
| Mounting | Desktop/ Wall-Mount |
| LEDs | 1x tri-color LED for device tracking and status indication, 10x green-color LEDs for data ports, 8x yellow-color LEDs for PoE ports |
| Environmental | Operation: 0°Cto 45°C, humidity 10-90% RH (Non-condensing) Storage: -10°C to 60°C, humidity: 5% to 95% (Non-condensing) |
| Dimensions | 30(L)*175(W)*44(H) mm |
| Unit Weight (TBD) | 2Kg |
